OUR PRODUCTS

STANDARD FLOATS

(CENTER WELDING & BOTH SIDE WELDING)

Details:

  • It will work from Specific Gravity 1 to 0.9.
  • Hydro up to 10kg Pressure
  • Temperature 150 deg cen.
  • Size 48.5mm O.D x 200mm Or 50mm O.D x 200mm Length.
  • Generally used Material : S.S 316 L (Depend on your Liquid Acceptance).
  • This Float is used for Magnetic Level Indicators, Roller & Capsule types.
Enquire now

RING FLOATS

(TOP & BOTTOM WELDING)

Details:

  • It will work from Specific Gravity 1 to 0.8.
  • Hydro upto 25kg Pressure.
  • Temperature 200 deg cen.
  • Size 48.5mm O.D x 250mm Length Or 50mm O.D x 250mm Length.
  • Generally Used Material : SS 316 L ( Depend on your Liquid Acceptance).
  • This Float is used for Magnetic Level Indicators, Roller & Capsule types.
Enquire now

LOW DENSITY FLOATS

Details:
  • We Design Low Density Floats given on the data from customer.
  • Date Req. Liquid : Name, Specific Gravity, Viscosity, Temperature, Pressure & Other details.
  • As we have great experience & knowledge on industry, chances are less for failure.
  • Sizes again depend on above given data.
  • Generally Used Material : TITANIUM ( Depend on your Liquid Acceptance).
  • This Float is used for Magnetic Level Indicators, Roller & Capsule types.

Enquire now

LOW DENSITY & HIGH PRESSURE FLOATS

Details:

  • We Design Low Density & High Pressure Floats.
  • Floats is Design as per data given by customer.
  • We share video of Hydro Test for Float.
  • This Float is used for Magnetic Level Indicators, Roller & Capsule types.
Enquire now

CUSTOMIZE FLOAT FROM DIFFERENT MATERIAL

Details:
  • Customise Float is design from different  material like Hastelloy – C, Alloy – 20, Tantalum, Inconel & many others.
  • This Float is design for specific purpose or acceptance to Liquid, or environment.
  • Due to good knowledge for raw material we can help to our customers select material for specific Liquid.
Enquire now

ID FLOAT

Details:

  • We design floats for Float Level Switches & Float Level Transmitter.
  • As per the customer requirement we suggest floats.
Enquire now

NON – MAGNETIC FLOATS OR FLOAT BALLS

Details:

  • This Floats or Floats Balls are generally design for Side Mounted Switches, Top Mounted Level Indicators, Ball Valves & Other Switches.
  • We design this float as per the data of customer.
  • All the standard sizes are available with use, with any threading required.
  • Material used : SS 316L & Titanium.
Enquire now
